Engine Model: Komatsu SAA6D125E-7
Number of Cylinders: 6
Bore * Stroke: 4.92 in * 5.91 in
Piston Displacement: 671 in³
Aspiration: Turbo-charged, after-cooled, cooled EGR
Komatsu Truck
The Komatsu Dump Truck series, designed for large-scale material transport in rugged environments, is built to handle demanding tasks in mining, construction, and quarry operations. With a payload capacity ranging from 30 to 400 tonnes, these trucks are optimized for heavy-duty hauling in tough terrains and extreme working conditions. The trucks are engineered to operate efficiently in diverse climates, with temperature tolerance from -40 to +50 degrees Celsius, ensuring reliable performance in both hot and cold environments.
Powered by advanced Komatsu engines, ranging from 300 kW (402 hp) to 2,000 kW (2,682 hp), these dump trucks provide exceptional power and fuel efficiency. The advanced transmission system combines power with smooth control, ensuring excellent traction and stability when navigating steep slopes and uneven ground. The heavy-duty chassis and high ground clearance make these trucks well-suited for navigating rough terrains, while the durable tires provide maximum grip and longevity.
Whether used in mining operations to transport extracted material or in large-scale construction projects, Komatsu Dump Trucks are designed to maximize productivity. Their robust structure and capacity for heavy material handling make them a reliable choice for operations requiring high output and minimal downtime. Equipped with the latest safety features, such as anti-collision systems and optimized braking technology, these trucks prioritize operator safety while maintaining top-tier performance.
As part of EMAC, ConeMac integrates DCEC engines, provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
The company provides customers with full life cycle services, from design to power system supply, installation and commissioning, to after-sales service training and spare parts supply, as well as troubleshooting and overhaul technical support. This full range of services ensures that customer equipment maintains high reliability and long-term operating efficiency during use.
These comprehensive power systems and service capabilities enable Duramac to occupy an important position in the field of construction machinery and provide advanced solutions for future electrification trends.
Komatsu Truck Series Main Feature
- High Payload Capacity: With a maximum capacity of 400 tons, ideal for large-scale mining and construction projects.
- Powerful Performance: Equipped with advanced Komatsu engines, providing excellent power and fuel efficiency.
- Durability: Robust chassis and high ground clearance design for handling rugged terrains, reducing downtime.
- Safety Features: Includes advanced safety systems like anti-collision technology and optimized braking systems.
- Efficient Transport: Smooth transmission and excellent traction for stable and efficient hauling operations.
General Specifications of Komatsu Truck Series
| Payload Capacity: | 30 -400 tons |
| Engine Power: | 300 – 2000 kW |
| Max Speed: | 40 – 64 km/h |
| Fuel Tank Capacity: | 600 -1500 L |
Komatsu Truck
This is the list of all series of Komatus truck.
- HM300 | 53 MT
- HM400 | 75 MT
- HD325 | 70 MT
- HD405 | 77 MT
- HD465 | 105 MT
- HD605 | 114 MT
- HD785 | 166 MT
- HD1500 | 249 MT
- 730E | 338 MT
- 830E | 411 MT
- 860E | 454 MT
- 930E | 521 MT
- 980E | 627 MT
Komatsu SAA6D140E-7 Engine for Komatsu HM400-5 Truck
Engine Model: Komatsu SAA6D140E-7
Number of Cylinders: 6
Bore * Stroke: 5.51 in * 6.5 in
Piston Displacement: 928 in³
Aspiration: Komatsu variable geometry, turbo-charged, after-cooled, cooled EGR
Komatsu SAA6D140E-7 Engine for Komatsu HD325-8 Truck
Engine Model: Komatsu SAA6D140E-7
Number of Cylinders: 6
Bore * Stroke: 5.5 in * 6.5 in
Piston Displacement: 930 in³
Aspiration: Variable geometry, turbo-charged, air-to-air after-cooled, cooled Exhaust Gas Recirculation (EGR)
Komatsu SAA6D140E-7 Engine for Komatsu HD405-8 Truck
Engine Model: Komatsu SAA6D140E-7
Number of Cylinders: 6
Bore * Stroke: 5.5 in * 6.5 in
Piston Displacement: 930 in³
Aspiration: Komatsu variable geometry, turbo-charged, after-cooled, cooled EGR
Komatsu SAA6D170E-7 Engine for Komatsu HD465-10 Truck
Engine Model: Komatsu SAA6D170E-7
Number of Cylinders: 6
Bore * Stroke: 6.69 in * 6.69 in
Piston Displacement: 1413 in³
Aspiration: Variable geometry, turbo-charged, air-to-air after-cooled, cooled Exhaust Gas Recirculation (EGR)
Komatsu SAA6D170E-7 Engine for Komatsu HD605-10 Truck
Engine Model: Komatsu SAA6D170E-7
Number of Cylinders: 6
Bore * Stroke: 6.69 in * 6.69 in
Piston Displacement: 1413 in³
Aspiration: Variable geometry, turbo-charged, air-to-air after-cooled, cooled Exhaust Gas Recirculation (EGR)
Komatsu SAA12V140E-7 Engine for Komatsu HD785-8 Truck
Engine Model: Komatsu SAA12V140E-7
Number of Cylinders: 12
Bore * Stroke: 5.51 in * 6.50 in
Piston Displacement: 1860 in³
Aspiration: Turbo-charged, after-cooled, cooled EGR
Komatsu SDA16V159E-3 Engine for Komatsu HD1500-8E0 Truck
Engine Model: Komatsu SDA16V159E-3
Number of Cylinders: 16
Bore * Stroke: 6.26 in * 6.26 in
Piston Displacement: 3082 in³
Aspiration: Overhead valve, direct injection type, turbocharged, after-cooled
Komatsu SSDA16V159E-2 Engine for Komatsu 730E-10 Truck
Engine Model: Komatsu SSDA16V159E-2
Number of Cylinders: 16
Operating Cycle: 4 cycle
Piston Displacement: 1860 in³
Aspiration: Turbo-charged, after-cooled, cooled EGR
Cummins QSB6.7 Engine for Komatsu HX16 UGHR Haulage
Engine Model: Cummins QSB6.7
Output: 220 HP @ 2,200 rpm
Air Filtration: Donaldson (dry type)
Exhaust System: Diesel oxidation catalyzer
Fuel Tank Capacity: 84 US gal
Komatsu SDA16V160 Engine for Komatsu 830E-5 Truck
Engine Model: Komatsu SDA16V160
Number of Cylinders: 16
Operating Cycle: 4 cycle
Piston Displacement: 1860 in³
Aspiration: Turbo-charged, after-cooled, cooled EGR
Komatsu SSDA16V160 Tier 2 Engine for Komatsu 860E-1K Truck
Engine Model: Komatsu SSDA16V160 Tier2
Number of Cylinders: 16
Operating Cycle: 4 cycle
Piston Displacement: 1860 in³
Aspiration: Turbo-charged, after-cooled, cooled EGR
Komatsu SSDA18V170 Engine for Komatsu 930E-5SE Truck
Engine Model: Komatsu SSDA18V170
Number of Cylinders: 18
Operating Cycle: 4 cycle
Weight (wet): 25,897 lbs.
Weight (dry): 24,798 lbs.
Komatsu SSDA16V160 Engine for Komatsu 930E-5 Truck
Engine Model: Komatsu SSDA16V160
Number of Cylinders: 16
Operating Cycle: 4 cycle
Weight (wet): 19,767 lbs.
Weight (dry): 18,675 lbs.
Komatsu SDA16V190-1 Engine for Komatsu 980E-5SE Truck
Engine Model: Komatsu SDA16V190-1
Number of Cylinders: 16
Operating Cycle: 4 cycle
Weight (wet): N / A
Weight (dry): 29,950 lbs.
Komatsu SSDA18V170 Engine for Komatsu 980E-5 Truck
Engine Model: Komatsu SSDA18V170
Number of Cylinders: 18
Operating Cycle: 4 cycle
Weight (wet): 25,897 lbs.
Weight (dry): 24,795 lbs.
